The automatic vertical liquid pouch packing machine uses intelligent control, precise servo-driven film transport, and flexible bag-making options to efficiently package various liquids into back seal bags.
Item No :
JS-420LYOrder(MOQ) :
1Payment :
L/C, D/P, D/A, T/T, Cash.Product Origin :
Guangdong, ChinaShipping Port :
Guangzhou Port / Shenzhen PortWeight :
650KGAutomatic Vertical Pouch Meshed Potato Date Paste Hummus Packing Machine
Description
The automatic vertical liquid pouch packing machine uses intelligent control, precise servo-driven film transport, and flexible bag-making options to efficiently package various liquids into back seal bags.
Description
The automatic liquid pouch packing machine completes bag making, metering, filling, sealing, coding, and cutting in one continuous process. It is suitable for packaging various liquids into back seal bags.
It is widely used in a variety of liquid, semi-liquid, paste, and viscous materials.
Food: olive oil, juice, syrup, jam, peanut butter, sesame paste, soy sauce, tartar sauce, pasta sauce, ketchup, and various sauces.
Daily necessities: shampoo, detergent, hand soap, disinfectant, and shower gel.
Specification
| Model | 420LY | 520LY | 720LY |
| Packing Speed | 5-30 bags/min | 5-30 bags/min |
10-25 bags/min |
| Filling Range | 50-1500ml | 200-2000ml |
300-4000ml |
| Bag Width | 60-200mm | 60-250mm | 80-350mm |
| Bag Length | 80-300mm | 80-350mm | 100-450mm |
| Roll Film Width | MAX.420mm | MAX.520mm |
MAX.720mm |
| Film Material | OPP/CPP, OPP/PE, PET/PE, aluminized film, etc. |
||
| Machine Size | 1388(L)*1116(W)*1536(H)mm | 1795(L)*1150(W)*1650(H)mm |
1780(L)*1350(W)*1950(H)mm |
| Voltage | 220V, 50/60Hz |
||
| Power | 2.2KW | 3KW | 3.6KW |
| Machine Weight | 650KG | 750KG | 950KG |
Main Feature
1. Fully automatic operation, bag making, metering, filling, sealing, coding, and cutting are all completed in one operation.
2. Utilizing an intelligent PLC control system, the machine operates reliably, stably, intuitively, and efficiently.
3. A servo motor-driven film transport system ensures precise positioning and excellent overall performance.
4. Multiple automatic alarm protection features minimize losses.
5. The bag-making unit can be replaced based on specific customer and product requirements.
6. Machine parameters can be set via the touchscreen, making operation simple and convenient.
